Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700

Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700

Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700
Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700Sinbosen 2 ohm stable 3600 watts 2CH class d digital high power amplifier H1700
Categories1U DIGITAL AMPLIFIER
BrandSinbosen| Audio sound system manufacturer
ModelH-1700
2Ω Output power2x3600W
4Ω Output power2x2800W
8Ω Output power2x1700W
8Ω Bridge power5600W
4Ω Bridge power7200W
Voltage90V-240V
Special serviceOEM service offered
Damping coefficient>600
Minimum load impedanceStereo 2Ω
Gross weight9.5kg
Terms of PaymentWestern Union, T/T, Paypal
Download
Update TimeNov 5,2024
Detail Information

PFC Wide Voltage Class D 1U Digital 2 ohms Stable Power Amplifier




H1700 PRODUCT FEATURES:

 Powerful output in so small shell space.

 Compact construction, only 1U height, 9" depth and lightweight, easy to move and install.

 Fixed switch frequency Class-D  PCB module.

 Soft resonant switching power supply LLC  module.

 Active power factor correction technique (PFC), can work with high stability under full voltage range 90-264V.

 High-efficiency loudspeaker EMF absorption system.

 Unique peak clipping limiter and ripple Elimination.

 Low electricity consumption.

 The nice cooling system with quality fans to make wind flow front to the rear.

 Accurate volume control, switch on/off, signal, clip and protection LED light in the front panel.

 Fully automatic protections against the direct current, overheat, overload, on/off switching, RF and amplitude limit.

 XLR balance input and professional SPEAKON output connectors.

 Stereo, bridge and mono mode selection pull switch is set on the back panel.

 Good choice for applications in the live show, outdoor event, stadium, and flow performance.







Model number: H-1700
8Ω Output power: 2x1700W
4Ω Output power: 2x2800W
2Ω Output power: 2x3600W
8Ω Bridge power: 5600W
4Ω Bridge power: 7200W
Net weight: 8.35KG
Gross weight: 9.5KG
Input resistance: Balance/unbalance >20kΩ/>10kΩ
Total harmonic distortion: 1KHz sine <0.035%
Frequency response: 20Hz-20kHz <+/- 0.5dB
Signal to noise ratio: >106dB
Damping coefficient: >600
Conversion rate: >20V/us
Input sensitivity: 32dB, 1V, 0.775V
Minimum load impedance: Stereo 2Ω
Wind direction: Blowing from the front to the rear, the temperature controls the wind speed
Protective function: Soft start, VHF, DC, short circuit, overload, clipping / distortion limit, thermal
Packing Size(H x W x D): 540 x 400 x 120 (mm)
