AXT220D Dynamic / Condenser Digital wireless Handheld microphone

Categories	WIRELESS MICROPHONE SYSTEM
Brand	Sinbosen\| Audio sound system manufacturer
Model	AXT220D
Type	Professional digital wireless microphone
Working effective distance	400 meters
Frequency range	UHF 513-558mhz, 615-665mhz, 780-820mhz.
Application	Stage Performance, Karaoke, DJ, Concert, KTV
Handheld Mic Color	Black, Silver
Feature	Perfect Sound
Channels	dual channel
Maximum deviation	± 45kHz
Integrated S / N ratio	> 108 dB
Transmitter	Handheld/Headset/Lavalier Microphone
Service	Logo customization
Terms of Payment	Western Union, MoneyGram, T/T, Paypal
Update Time	2022/5/28

Contact Now

Favorites

Detail Information

UHF true diversity digital wireless microphone AXT 220D


Modulation method: FM Oscillation method: PLL phase-locked frequency synthesizer Frequency stability: ± 0.0005% Sensitivity: S / N> 60dB when the offset is equal to 25KHz and input 6dBμV Maximum deviation: ± 45kHz Bandwidth: 40MHz Integrated S / N ratio:> 108 dB General T.H.D.: <0.4% @ 1 KHz Integrated frequency response: 65Hz ~ 18kHz ± 3dB Maximum output voltage: Balanced: -20dBV / 100Ω Unbalanced: -4dBV / 5KΩ Output socket: XLR balanced and 6.3φ unbalanced socket Power supply: 100 - 240V AC50 / 60 Hz, 10W	Frequency range: UHF 513-558 mhz, 15-665mhz, 780-820mhz Oscillator mode: PLL phase-locked frequency synthesizer Harmonic radiation: <-63dBm Bandwidth: 80MHz Maximum deviation: ± 45KHz Power output: 30mW Frequency response: 50Hz ~ 18KHz The maximum input sound pressure: 130dB SPL Sound head: moving coil Battery: AA × 2 Current consumption: <110 mA

Modulation method: FM
Oscillation method: PLL phase-locked frequency synthesizer
Frequency stability: ± 0.0005%
Sensitivity: S / N> 60dB when the offset is equal to 25KHz and input 6dBμV
Maximum deviation: ± 45kHz
Bandwidth: 40MHz
Integrated S / N ratio:> 108 dB
General T.H.D.: <0.4% @ 1 KHz
Integrated frequency response: 65Hz ~ 18kHz ± 3dB
Maximum output voltage: Balanced: -20dBV / 100Ω
Unbalanced: -4dBV / 5KΩ
Output socket: XLR balanced and 6.3φ unbalanced socket
Power supply: 100 - 240V AC50 / 60 Hz, 10W

Frequency range: UHF 513-558 mhz, 15-665mhz, 780-820mhz
Oscillator mode: PLL phase-locked frequency synthesizer
Harmonic radiation: <-63dBm
Bandwidth: 80MHz
Maximum deviation: ± 45KHz
Power output: 30mW
Frequency response: 50Hz ~ 18KHz
The maximum input sound pressure: 130dB SPL
Sound head: moving coil
Battery: AA × 2
Current consumption: <110 mA
